Progressive Safety Gear for Passenger Lift

Share to:

Progressive Safety Gear for Passenger Lift

Availability:

Quantity:



Inquire Add to Basket

Type:
Safety System
Load Capacity:
947-4122kgs
Persons:
11-20
Speed:
<2.5m/S
Drive Mode:
AC
Control Type:
Relay Control

Product Description

Nova has been started to provide elevator safety parts since 2002. All our safety parts have CE , Test Report and ISO Certification.You can find more details from our web: novaelevator.en.made-in-china.com.
We can supply two types of elevator safety gear as below:
1. Progressive Safety Gear For Passenger Elevator (NV51-210A,NV51- 188, NV51- 188A)
2. Instantaneous Safety Gear For Villa Elevator ( NV51-088, NV51- 288, NV51- 388 )

Progressive Safety Gear (used for passenger elevator)	NV51-210A	Lift rated speed	≤2.5m/s
		Allowable gross mass(P+Q)	1108-3953kg
		Width of guide rail	10/15.88/16mm
	NV51-188	Lift rated speed	≤2.5m/s
		Allowable gross mass(P+Q)	1045-4467kg
		Width of guide rail	10/15.88/16mm
	NV51-188A	Lift rated speed	≤2.5m/s
		Allowable gross mass(P+Q)	1500-6550kg
		Width of guide rail	15.88/16mm
Instantaneous Safety Gear (used for villa elevator)	NV51-088	Lift rated speed	≤0.63m/s
		Allowable gross mass(P+Q)	≤1506kg
		Width of guide rail	10mm
	NV51-288	Lift rated speed	≤0.63m/s
		Allowable gross mass(P+Q)	≤3602kg	≤7161kg
		Width of guide rail	10mm	15.88/16mm
	NV51-388	Lift rated speed	≤0.63m/s
		Allowable gross mass(P+Q)	≤12148kg
		Width of guide rail	16mm

All my good friends, please feel free to contact us if you have any inquiry!
