AC Elevator
320-1600kg
4-21 Persons
0.5-4.0m/S
Collective Selective Control
Mr or Mrl
| Nova Code | Capacity(KGS) | Speed(m/s) | Power(KW) | Traction Sheave(mm) | Roping | Voltage(V) | Travel Height |
| NV41T-ERS | 320 | 1 | 2.2 | Φ320*3*Φ8*12 | 2:1 | AC380V(Stanard) AC220V(Optional) | <=80M |
| 1.5 | 3.3 | Φ320*3*Φ8*12 | |||||
| 1.6 | 3.5 | Φ320*3*Φ8*12 | |||||
| 1.75 | 3.8 | Φ320*3*Φ8*12 | |||||
| 450 | 1 | 3 | Φ320*4*Φ8*12 | ||||
| 1.5 | 4.5 | Φ320*4*Φ8*12 | |||||
| 1.6 | 4.8 | Φ320*4*Φ8*12 | |||||
| 1.75 | 5.3 | Φ320*4*Φ8*12 | |||||
| NV41T-ER1 | 630 | 1 | 4.5 | Φ320*5*Φ8*12 | |||
| 1.5 | 6.7 | Φ320*5*Φ8*12 | |||||
| 1.6 | 7.2 | Φ320*5*Φ8*12 | |||||
| 1.75 | 7.9 | Φ320*5*Φ8*12 | |||||
| NV41T-ER2 | 800 | 1 | 5.6 | Φ320*6*Φ8*12 | |||
| 1.5 | 8.4 | Φ320*6*Φ8*12 | |||||
| 1.6 | 9 | Φ320*6*Φ8*12 | |||||
| 1.75 | 9.8 | Φ320*6*Φ8*12 | |||||
| 1000 | 1 | 6.9 | Φ320*7*Φ8*12 | ||||
| 1.5 | 10.3 | Φ320*7*Φ8*12 | |||||
| 1.6 | 11 | Φ320*7*Φ8*12 | |||||
| 1.75 | 12 | Φ320*7*Φ8*12 |
| Contact | Ms. Jessie Chi |
| 0086 180 136 10266 | |
| TEL.: | 0086-512- 5677 1008 |
| FAX: | 0086-512-5879 5609 |
| Web: | novaelevator.en.made-in-china.com novaelevator.en.made-in-china.com |
| novaelevator06 |
