Safety System
Elevator
3000kg
6-10
1.00-2.00m/s
AC
| Product Name | Description | |
| Bi-directional Overspeed Governor | Model | NV52-240F |
| Rated Speed | <=2.5m/s | |
| Wire Rope Diameter(mm) | Φ6, Φ8 | |
| Sheave Diameter(mm) | Φ240mm | |
| Tension Force | >=1000N | |
| Overspeed Switch Voltage | AC220V | |
| Bi-directional Overspeed Governor | Model | NV52-240B |
| Rated Speed | <=2.5m/s | |
| Wire Rope Diameter(mm) | Φ6, Φ8 | |
| Sheave Diameter(mm) | Φ240mm | |
| Tension Force | >=1000N | |
| Overspeed Switch Voltage | AC220V | |
| Bi-directional Overspeed Governor for MRL | Model | NV52-240E |
| Rated Speed | <=0.63m/s | |
| Wire Rope Diameter(mm) | Φ6, Φ8 | |
| Sheave Diameter(mm) | Φ240mm | |
| Tension Force | >=1000N | |
| Overspeed Switch Voltage | AC220V/DC24V | |
| Switch Electromagnetic Voltage | AC220V/DC24V | |
| Action Electromagnetic Voltage | AC220V/DC24V | |
| Uni-directional Overspeed Governor for MRL | Model | NV52-240A |
| Rated Speed | <=1.75m/s | |
| Wire Rope Diameter(mm) | Φ6, Φ8 | |
| Sheave Diameter(mm) | Φ240mm | |
| Tension Force | >=1000N | |
| Overspeed Switch Voltage | AC220V/DC24V | |
| Switch Electromagnetic Voltage | AC220V/DC24V | |
| Action Electromagnetic Voltage | AC220V/DC24V | |
| Bi-directional Overspeed Governor for MRL | Model | NV52-187 |
| Rated Speed | <=1.75m/s | |
| Wire Rope Diameter(mm) | Φ6, Φ8 | |
| Sheave Diameter(mm) | Φ240mm | |
| Tension Force | >=500N | |
| Overspeed Switch Voltage | AC220V/DC24V | |
| Switch Electromagnetic Voltage | AC220V/DC24V | |
| Action Electromagnetic Voltage | AC220V/DC24V | |
| Bi-directional Overspeed Governor for MRL Home Elevator | Model | NV52-186 |
| Rated Speed | <=0.63m/s | |
| Wire Rope Diameter(mm) | Φ6 | |
| Sheave Diameter(mm) | Φ200mm | |
| Tension Force | >=500N | |
| Overspeed Switch Voltage | AC220V/DC24V | |
| Switch Electromagnetic Voltage | AC220V/DC24V | |
| Action Electromagnetic Voltage | AC220V/DC24V | |
| Uni-directional Overspeed Governor | Model | NV52-240 |
| Rated Speed | <=2.5m/s | |
| Wire Rope Diameter(mm) | Φ6, Φ8 | |
| Sheave Diameter(mm) | Φ240mm | |
| Tension Force | >=1000N | |
| Overspeed Switch Voltage | AC220V/DC24V | |
| Product Name | Description | |
| Bi-directional Overspeed Governor | Model | NV52-240F |
| Rated Speed | <=2.5m/s | |
| Wire Rope Diameter(mm) | Φ6, Φ8 | |
| Sheave Diameter(mm) | Φ240mm | |
| Tension Force | >=1000N | |
| Overspeed Switch Voltage | AC220V | |
| Bi-directional Overspeed Governor | Model | NV52-240B |
| Rated Speed | <=2.5m/s | |
| Wire Rope Diameter(mm) | Φ6, Φ8 | |
| Sheave Diameter(mm) | Φ240mm | |
| Tension Force | >=1000N | |
| Overspeed Switch Voltage | AC220V | |
| Bi-directional Overspeed Governor for MRL | Model | NV52-240E |
| Rated Speed | <=0.63m/s | |
| Wire Rope Diameter(mm) | Φ6, Φ8 | |
| Sheave Diameter(mm) | Φ240mm | |
| Tension Force | >=1000N | |
| Overspeed Switch Voltage | AC220V/DC24V | |
| Switch Electromagnetic Voltage | AC220V/DC24V | |
| Action Electromagnetic Voltage | AC220V/DC24V | |
| Uni-directional Overspeed Governor for MRL | Model | NV52-240A |
| Rated Speed | <=1.75m/s | |
| Wire Rope Diameter(mm) | Φ6, Φ8 | |
| Sheave Diameter(mm) | Φ240mm | |
| Tension Force | >=1000N | |
| Overspeed Switch Voltage | AC220V/DC24V | |
| Switch Electromagnetic Voltage | AC220V/DC24V | |
| Action Electromagnetic Voltage | AC220V/DC24V | |
| Bi-directional Overspeed Governor for MRL | Model | NV52-187 |
| Rated Speed | <=1.75m/s | |
| Wire Rope Diameter(mm) | Φ6, Φ8 | |
| Sheave Diameter(mm) | Φ240mm | |
| Tension Force | >=500N | |
| Overspeed Switch Voltage | AC220V/DC24V | |
| Switch Electromagnetic Voltage | AC220V/DC24V | |
| Action Electromagnetic Voltage | AC220V/DC24V | |
| Bi-directional Overspeed Governor for MRL Home Elevator | Model | NV52-186 |
| Rated Speed | <=0.63m/s | |
| Wire Rope Diameter(mm) | Φ6 | |
| Sheave Diameter(mm) | Φ200mm | |
| Tension Force | >=500N | |
| Overspeed Switch Voltage | AC220V/DC24V | |
| Switch Electromagnetic Voltage | AC220V/DC24V | |
| Action Electromagnetic Voltage | AC220V/DC24V | |
| Uni-directional Overspeed Governor | Model | NV52-240 |
| Rated Speed | <=2.5m/s | |
| Wire Rope Diameter(mm) | Φ6, Φ8 | |
| Sheave Diameter(mm) | Φ240mm | |
| Tension Force | >=1000N | |
| Overspeed Switch Voltage | AC220V/DC24V | |
