30W Power Elevator Wall Hanging Hot Sale Air Sterilizer Disinfection Purifier

Share to:

30W Power Elevator Wall Hanging Hot Sale Air Sterilizer Disinfection Purifier

Availability:

Quantity:



Inquire Add to Basket

After-sales Service:
Online Technical Support
Warranty:
1 Year
Type:
Elevator Air Sterilizer
Suitable for:
Elevator
Load Capacity:
3000kg
Persons:
6-10

Product Description

Product Outline 1. Double functions of highly efficient disinfection and purification 2. All-round disinfection and purification of elevator air and walls 3. Peaceful coexistence of human and machine to realize real-time 4. disinfection and purification 5. Ultar-thin design for easy installation and maintenance 6. Intelligent biological recognition 7. Internet of Things optional

Specification

Size	30015066mm
Weight	1.5kg
Circulation air volume	60m3/h @0Pa
Virus (A and B) killing efficiency	99%
Virus (MERS-CoV) killing efficiency	98%
30WRated power	30W
Adapter rated voltage	220V 50/60Hz
Maximum operating current	1.25A(24v DV)
Power adapter output voltage	24V DC
Range of working temperature	-20ºC~45ºC

Ways of Installation

It is recommended to punch the bottom hole 150 mm from the top of the cage side wall. (Reserving top routing and operating space, and the crossing diameter is recommended to be no less than 20mm) Ps. The positioning holes is recommended as 4.5mm for plate of 1.5-1 8mm in thickness; and 4. 6mm for plate of 1.8-2.5mm in thickness. (Schematic diagram 1)

Tear off 3M tape on back of machine. (Schematic diagram 2)

Align the hanging hole on the top of purifier with posstioning hole and attach the machine on the wall. Then screw in self-tapping bolt slowly with electricalscrewdriver and hexagon sleeve. Ps. The torque varies according to different plate thickness and material. Pls screw with small strength to avoid the breakdown of bolt and adjust the strength little by little. (Schematic diagram 3)

Connect adaptor and purifier (Schematic diagram 4) and plunge the other end of cable into 220V power source. Then the disinfection machine works by pressing the button.

30W Power Elevator Wall Hanging Hot Sale Air Sterilizer Disinfection Purifier Air Sterilizer Purifier

30W Power Elevator Wall Hanging Hot Sale Air Sterilizer Disinfection Purifier
